Description
Knee airbag for CITROËN C5 vehicles from 2005 to 2007. Color HZW – Matinal Grey.
This knee airbag (OE references 9650141200 / 96501412 / 8216EV) is a direct-fit interior safety component designed for Citroën C5 first‑generation models produced between 2005 and 2007. Frequently searched by part number, this unit restores proper lower‑limb protection after deployment or repair and maintains original interior appearance with the Matinal Grey finish (color code HZW).
Features and Function
The knee airbag is mounted under the instrument panel and deploys in a moderate to severe frontal impact to reduce leg and pelvis injuries by controlling occupant lower‑body movement. It works together with the driver and passenger frontal airbags and seat belt restraining systems. The unit includes the airbag module, inflator and connector harness interface that communicates with the vehicle’s restraint control system.
Compatibility and Fitment
Designed to fit Citroën C5 (first generation) models built approximately 2005–2007. Confirm fitment by matching OE/product codes listed below. This part is typically used in saloon and estate variants of the listed generation.
Replacement Procedure (Overview)
- Disconnect the negative battery terminal and wait at least 10 minutes to allow the restraint system capacitors to discharge.
- Carefully remove lower dash trim and any panels securing the knee airbag to expose mounting bolts and the electrical connector.
- Unbolt the module, disconnect the airbag connector, and remove the old unit. Handle the module by its frame, avoid contact with the airbag cushion or inflator.
- Install the replacement module, reconnect the connector, and torque fasteners to manufacturer specifications.
- Reinstall trim panels, reconnect the battery, and verify that the airbag indicator on the instrument cluster behaves according to the vehicle’s diagnostic procedure (light out after self‑check).
Installation Recommendations
- Always disconnect the battery before starting work and observe electrostatic discharge precautions.
- Use correct tools and torque settings for mounting screws; do not overtighten plastic trim fasteners.
- Avoid striking or placing tools on the airbag module and do not apply cleaning solvents to the inflator area.
- If the airbag warning lamp remains on after fitment, perform a diagnostic scan with compatible equipment to clear fault codes and confirm proper communication with the SRS control unit.
- If in doubt about SRS diagnostics or wiring, seek installation by a qualified technician experienced with vehicle restraint systems.
Most Common Reasons For Failure
Typical causes for knee airbag replacement include: deployment during a collision, electrical connector corrosion or damage, water ingress behind the dash, prior improper removal or impact damage, and age‑related deterioration of mounting points or harness insulation. Once deployed, the module must be replaced.
Technical Information
- Manufacturer: Citroën / Stellantis
- Model: Citroën C5 (2005–2007)
- Product Codes: 9650141200, 96501412, 8216EV
- Other Numbers: 96501412 00, Color Code HZW (Matinal Grey)
